Overview

To get peace of mind, you need to secure yourself, your home and your personal belongings. Yale Digital Door Locks take care of all this so that you can enjoy your life without any worries. In these products we have combined our long experience in making secure and reliable locks with the latest technology for convenience and safety.

The secure smart lock allows you to lock and unlock your door, send virtual keys to guests and receive notifications all via the Yale Access App. You can gain access in a way that suits you, with the options to use a PIN code or RFID card/tag for simple and convenient access to your home.

Features

  • Smart touchpad
  • Various access options by RFID proximity card identification, PIN code or key for your convenience
  • Yale Access module provides Bluetooth connectivity and the ability to connect to the Yale Access app (sold separately)
  • Yale Access Bridge remote access via app (sold separately)
  • Easy registration of key tags
  • Scrambling code
  • Mechanical override key
  • Break-in alarm
  • Manual and automatic locking selection
  • Anti-panic egress
  • Safe handle, ideal for small children
  • Low battery warning and emergency power contacts
  • Voice guide feature
  • IP X4 rating provides protection against splash water from any direction e.g. rain

Accessories
There are a range of digital door lock accessories available, including, spare key tags, rebate kits, strike kits and modules. Yale Access Module for App functionality and Yale Connect Wi-Fi Bridge for locking/unlocking remotely and voice assistants. (accessories  sold separately)

Smart together (Access Module and bridge required)
Connect your YDM3109A Smart Lock with leading smart home systems, voice assistants and holiday rental platforms for effortless lock control and access management including:

  • Google Assistant
  • Amazon Alexa
  • Airbnb
  • IFTTT

Connects with Yale YDM Access Kit:

  • Yale Connect WiFi Bridge  (sold separately)- For functionalities such as locking and unlocking your door remotely, instant alerts to your phone and for integrations like voice assistants.
  • Yale Access Module (sold separately)-Our Smart Locks can benefit from increased app functionalities and form part of the Yale Access range.
Specifications

Technical details

  • Mortice lock
  • Backset: 60mm
  • Minimum lock stile clearance: 100mm
  • 4 x Proximity Key tags - up to 100 key tags can be registered
  • 2 x Mechanical keys
  • 4-10 digit pin code - up to 100 pin codes can be registered
  • Outside trim dimension 27mmx 68.6mmx 306.6mm - w/o lever
  • Suitable for 40-80 mm thick aluminium or wooden door
  • Application: Sheltered entrance
  • Finish: Silver

Warranty

3 Year Warranty from date of purchase backed by Yale NZ (Assa Abloy NZ)
